Newcon Optik is a world leader in the laser rangefinder field. Each of our highly ruggedized models utilizes advanced laser, electronic and optical technologies not only to measure distance, but to provide a variety of other geospatial target information.

In addition to having NATO target measurement ranges spanning 1,500 to 12,000 meters, many of our models can be used with our AndroidTM – based application, allowing for real-time target mapping and geospatial data communication via mobile phones and tablets.

MONOCULARS

  • LRM 3500M – 35BT

    The LRM 3500M-35BT is the world’s most advanced miniaturized laser rangefinder monocular. Weighing just 460 grams, the LRM 3500M-35BT is capable of measuring distance to targets out to 6 kilometers, but what truly sets this device apart from the rest is its built-in GPS receiver allowing for user and target coordinate measurement, digital magnetic compass, inclinometer, bright LED display, Bluetooth capability, Kestrel ballistic calculator and fully ruggedized design. Users can now communicate with the LRM 3500M-35BT using Newcon Optik’s new NC Cronus app. The LRM 3500M-35BT is the ideal tool for professionals who depend on the accuracy and ruggedness of their equipment to get the job done.


    This device is compatible with:

    Android™      Bluetooth™      Ballistic app      NC Cronus™      CivTAK/ATAK

  • LRM 3500M – 35C

    NSN#: 1240-20-011-6212

    The LRM 3500M-35C is the world’s most advanced miniaturized laser rangefinder monocular. Weighing just 460 grams, the LRM 3500M-35C is capable of measuring distance to targets out to 6 kilometers, but what truly sets this device apart from the rest is its built-in Bluetooth capability, Kestrel ballistic calculator, digital magnetic compass, inclinometer, bright LED display, and fully ruggedized design. Users can now communicate with the LRM 3500M-35C using Newcon Optik’s new NC Cronus app. The LRM 3500M-35C is the ideal tool for professionals who depend on the accuracy and ruggedness of their equipment to get the job done.



    This device is compatible with:

    Android™      Bluetooth™      Ballistic app      NC Cronus™      CivTAK/ATAK

  • LRM 2200SI

    NSN#: 1240-20-009-0287

    The LRM 2200SI combines excellent 7x optics with the world’s most advanced laser rangefinder technology. Revised approaches in optical and electronic engineering allow target acquisition at longer distances with better reliability under a wider range of weather conditions.

    This model allows observation of distant objects with superb image quality plus it measures the distance to the object up to 2,200 meters (output display in yards also).

    The LRM 2200SI has a built-in inclinometer to measure the angle to the object, as well as speed detecting capability. Aim and click – and you have everything you want about your target. Compatible with our new NC Cronus app.



    This device is compatible with:

    Bluetooth™             NC Cronus™

  • LRM 2K

    NSN#: 1240-20-A0X-5255

    The state-of-the-art LRM 2K combines excellent 7x optics with the world’s most advanced laser rangefinder technology. Revised approaches in optical, mechanical and electronic engineering allow target acquisition at longer distances with better reliability under a wide range of harsh weather conditions. This model allows observation of distant objects with superb image quality along with accurate distance measurement up to 2,000 m (output display in yards also) and has Bluetooth connectivity and bright TOLED display for round-the-clock operations. Compatible with our new NC Cronus app.

    The LRM 2K has a built-in inclinometer to measure the angle to the object. The LRM 2K is waterproof according to IP67 standard. Aim and click— and you know distance and elevation, all with the push of a single button.



    This device is compatible with:

    Bluetooth™             NC Cronus™



  • LRM 1800S

    The LRM 1800S combines excellent 7x optics with the world’s most advanced laser rangefinder technology. Revised approaches in optical and electronic engineering allow target acquisition at longer distances with better reliability under a wider range of weather conditions.

    This model allows observation of distant objects with superb image quality plus it measures the distance to the object up to 1,800 meters (output display in yards also).

    The LRM 1800S also has a built-in speed detector. Aim and click – and you have everything you want about your target. The model has a bright TOLED display for round-the-clock operation.

BINOCULARS

  • LRB 6K

    NSN#: 1240-20-010-6217

    The LRB 6K is built to outperform any handheld laser rangefinder binocular available today. Packing a virtually endless set of performance features into a MIL-SPEC form factor, the LRB 6K can handle anything professional operators can throw its way. A 6,000 metre (NATO target) measuring range, built-in digital magnetic compass, and a crystal-clear LED display are combined into an invaluable force multiplier.

    The LRB 6K requires virtually no maintenance and very little operational training. Through USB, Bluetooth and RS-232 interfaces, the LRB 6K can be operated remotely, have its stored data exported, and communicate with external GPS systems and ballistic computers (only with Bluetooth installed). Users can now communicate with the LRB 6K using Newcon Optik’s new NC Cronus app.



    This device is compatible with:

    Android™      Bluetooth™      Ballistic app      NC Cronus™      CivTAK/ATAK

  • LRB 6KNIGHT

    The LRB 6KNIGHT is built to outperform any handheld laser rangefinder binocular available today. Packing a virtually endless set of performance features into a MIL-SPEC form factor, the LRB 6KNIGHT can handle anything professional operators can throw its way. A 6,000 metre (NATO target) measuring range, built-in digital magnetic compass, and a crystal-clear LED display are combined into an invaluable force multiplier.

    The LRB 6KNIGHT requires virtually no maintenance and very little operational training. Through USB and RS-232 interfaces, the LRB 6KNIGHT can be operated remotely, have its stored data exported, and communicate with external GPS systems and ballistic computers. Users can now communicate with the LRB 6KNIGHT using Newcon Optik’s new NC Cronus app.



    This device is compatible with:

    Android™       Bluetooth™       Ballistic app       NC Cronus™

  • LRB 12K

    The LRB 12K is built to outperform any handheld laser rangefinder binocular available today. Packing a virtually endless set of performance features into a MIL-SPEC form factor, the LRB 12K can handle anything professional operators can throw its way.

    A 12,000 metre (NATO target) measuring range, built-in digital magnetic compass, built-in GPS receiver, and a crystal-clear LED display are combined into an invaluable force multiplier.

    The LRB 12K requires virtually no maintenance and very little operational training. Through USB and RS-232 interfaces, the LRB 12K can be operated remotely, have its stored data exported, and communicate with external GPS systems and ballistic computers. Users can now communicate with the LRB 12K using Newcon Optik’s new NC Cronus app.



    This device is compatible with:

    Android™         NC Cronus™



  • LRB 12KNIGHT

    The LRB 12KNIGHT is built to outperform any handheld day/night laser rangefinder binocular available today. Packing a virtually endless set of performance features into a MIL-SPEC form factor, the LRB 12KNIGHT can handle anything professional operators can throw its way. A 12,000 metre (NATO target) measuring range, built-in digital magnetic compass, built-in GPS receiver, crystal-clear LED display, and a Gen 3 night vision channel are combined into an invaluable force multiplier.

    The LRB 12KNIGHT requires virtually no maintenance and very little operational training. Through USB and RS-232 interfaces, the LRB 12KNIGHT can be operated remotely, have its stored data exported, and communicate with external GPS systems and ballistic computers. Users can now communicate with the LRB 12KNIGHT using Newcon Optik’s new NC Cronus app.



    This device is compatible with:

    Android™         NC Cronus™

  • LRB 3000PRO

    NSN#: 1240-20-004-5448

    The LRB 3000PRO laser rangefinder binocular combines uncompromised 7×40 optics with advanced data processing algorithms to measure target distances up to 3,000 meters (output display in yards also) while providing azimuth from a built-in digital compass.

    Low power-consumption (one battery lasts for more than 5000 shots), ergonomic rubber-armoured body, long eye-relief, simple two-button operation, and wide objective lenses make observation and distance measurement with these binoculars accurate and comfortable.

  • LRB 6000CI

    The LRB 6000CI medium range laser rangefinder binoculars combine uncompromised 7×50 optics with advanced data processing algorithms. The rangefinder instantly measures distance up to 6,000 meters (output display in yards also), accurate azimuth and inclination via an in-built digital magnetic compass, and speed using the highly accurate time-of-flight delay method. LRB 6000CI also features RS-232 interface that enables immediate data acquisition by computers, external GPS receivers and various ballistic computers.

    A gating algorithm implemented in LRB 6000CI dramatically improves reliability of measurement in unfavourable measurement conditions (e.g. rain, snow, bushes, wires, etc). Low power-consumption (one battery lasts for more than 5000 shots), ergonomic rubber-armoured body, long eye relief, simple two-button operation, and wide objective lenses make observation and distance measurement with these binoculars accurate and comfortable.

MOUNTABLE

  • SEEKER M

    The SEEKER M is a specially designed multi-purpose mountable laser rangefinder which can be a vital tool for various operations. This device can be mounted and aligned with any optical system including weapon sights and can be integrated with various purpose built platforms. The device incorporates the newest laser rangefinding technologies to help the operator not only seek the target, but also, based on compass and inclinometer indications.

    The SEEKER M also features a visible laser system which helps with referencing and adjustments. High strength materials as well as ergonomic control placement make this rugged device efficient and user friendly. Users can now communicate with the SEEKER M using Newcon Optik’s new NC Cronus app, and other Ballistic apps.



    This device is compatible with:

    Android™      Bluetooth™      Ballistic app      NC Cronus™      CivTAK/ATAK

MODULES

  • LRF MICRO 1550

    Designed for OEM integration, Newcon Optik’s LRF MICRO 1550 module provides accurate measurements for fire control systems, industrial machinery, border surveillance stations, weapon mounted systems and countless other applications.

    The MICRO 1550 unit is barely larger than a deck of cards. The LRF MICRO 1550 is one of four member of the MICRO family (MICRO, MICRO CI, MICRO 1550 CI).

    The unit ranges accurately out to 5.500m (3,000 to NATO target) and utilizes a 1550nm laser that cannot be seen by image intensified night vision systems, making it ideal for defense applications. The MICRO series supports the USB interface. Other features include gating capability, fast scan mode, speed measurement, and object selection, among others.

  • LRF MICRO 1550 CI

    Designed for OEM integration, Newcon Optik’s LRF MICRO 1550 CI module provides accurate measurements for fire control systems, industrial machinery, border surveillance stations, weapon mounted systems and countless other applications.

    The MICRO 1550 CI unit is barely larger than a deck of cards. The LRF MICRO 1550 CI is one of four member of the MICRO family (MICRO, MICRO CI, MICRO 1550).

    The unit ranges accurately out to 5.500m (3,000 to NATO target) and utilizes a 1550nm laser that cannot be seen by image intensified night vision systems, making it ideal for defense applications. The MICRO series supports the USB interface. Other features include gating capability, fast scan mode, speed measurement, and object selection among others.

  • LRF MOD 25HFLC

    This high-frequency laser rangefinder module enables highly accurate range acquisition of low reflection targets at ranges of up to 30 kilometres. The module can be effectively used in marine navigation, long-range reconnaissance, naval and coast guard patrol, and other professional applications requiring highly accurate, long distance measurements.

    Liquid cooling is no longer required for the MOD 25HFLC, which enables higher-frequency data acquisition up to 10Hz with no cooling time required. This gives the system the smallest footprint and weight profile.

    The unit can be integrated with other systems and communicate via RS-422. In designing this module for precision target acquisition, special attention was given to the ability to boresight the units with a pre-designed optical platform. A removable day sight with precise alignment to the laser is provided to enable quick boresighting and visual integration with other observation systems.

  • LRF MOD 6EC

    The LRF MOD 6EC was designed specifically for remotely operated small platforms. In addition to its outstanding functionality, this new module can be attached to Mini-Typhoon, CLAWS and other systems with a quick release mount. The unit is designed to endure the harsh operating conditions of the real world. It can withstand high vibration, a wide temperature range, dust, rain and RF jammers. The LRF MOD 6EC provides distance, speed, azimuth and elevation measurements. Other features include gating, fast scan and target selection.

    The unit can be integrated with other systems and communicate via RS-232. In designing this module for precision target acquisition, special attention was given to the ability to boresight the units with a pre-designed optical platform. A removable visual eyepiece and a video camera attachment are provided to enable quick boresighting and visual integration with other observation systems.

ACCESSORIES

  • SEEKER Hard Case

    MIL-SPEC hard case for protection while transporting/storing unit and its standard delivery set.

  • LRF Car Adapter

    Cigarette lighter adapter for LRM 3500M / LRB 6K / 12K /12KNIGHT.

  • LRF GPS Cable

    NSN#: 5995-20-011-6019

    For use with LRB 12K, 12KNIGHT and 6K; and LRB 4000CI and 6000CI. Connects devices to Rockwell Collins, DAGR, Polaris ™ and PLGR GPS receivers.

  • LRM Hard Case

    MIL-SPEC hard case for protection while transporting/storing unit and its standard delivery set.

  • LRF Smart Cable

    Connects LRM 3500M, LRB 12K, LRB 12KNIGHT or LRB 6K to the micro USB port of Android-based devices.

  • LRF AC/DC Adapter

    AC/DC Adapter for LRM 3500M / LRB 6K / 12K / 12KNIGHT.

  • TACT 3-S Tripod

    The TACT-3S Model Tactical Tripod was selected by the US Army and US SOCOM for use in their ground target location systems. The TACT-3S is “amagnetic” and will not adversely influence any sensor device equipped with a digital magnetic compass. The TACT-3S is a rugged combat proven field tripod platform with a terrain-leveling gimbal that allows the user to adjust the position of the optical device for uneven terrain.

    This tripod is for use with a wide range of high magnification field optics, laser range finders, thermal cameras and night vision devices. The TACT-3S weighs approximately three pounds, has a versatile tripod head with a detachable base plate, multi-section mast, and a wide stable tripod base. The mast can be detached from the tripod base and used with an internal stored ground spike as a monopod. Constructed of high-strength, lightweight, aerospace-grade aluminum alloys, the TACT-3S deploys quietly and provides rock solid stability. This field tripod design allows shooters to use field optics comfortably from the prone to sitting positions.

  • NVS U Coupler

    NSN#: 5855-20-011-6791

    NVS U Coupler is a clamp-on mechanical adapter with flip-out feature that provides the ability to attach a night vision monocular (NVS 14 /PVS 14) or goggles (NVS7/ PVS7) to various tactical daytime equipment such as Laser Range Finders, Spotting Scopes, Binoculars, Sniper Scopes, etc.
