AG Series

The AG series consists of advanced Generation 3 IITs with world-leading GaAs photocathode sensitivity and FOM. This series of IIT, like the AGBW series, incorporates an auto-gating system that automatically adjusts itself to limit the impact of changing light conditions—the effect of muzzle flash, vehicle lights and other intermittent battlefield light sources is significantly reduced by auto-gating technology.

AGBW Series

The AGBW series consists of advanced Generation 3 IITs with world-leading GaAs photocathode sensitivity and FOM. This series of IIT, like the AG series, incorporates an auto-gating system that automatically adjusts itself to limit the impact of changing light conditions—the effect of muzzle flash, vehicle lights and other intermittent battlefield light sources is significantly reduced by auto-gating technology. The black and white image produced by the AGBW series reduces eye strain and provides better contrast in certain light conditions.

GOGGLES

  • NVS 7-3AG

    The NVS 7-3AG night vision goggle has been proven in deployments in conflict zones and by peacekeepers around the world. It utilizes an advanced auto-gated, Gen 3 image intensifier tube, has a built-in IR illuminator, auto shutoff mechanism and is fully MIL-SPEC. Fitted with an optional 3x, 4x, 5x and 8x lens, this advanced goggle can be easily converted to a long range night vision binocular, and with a full range of additional accessories, the NVS 7 series is among the world’s most versatile night vision devices.

  • NVS 7-3AGBW

    The NVS 7-3AGBW auto-gated night vision goggle has been proven in deployments in conflict zones and by peacekeepers around the world. It utilizes an advanced auto-gated black and white, Gen 3 image intensifier tube; has a built-in IR illuminator; auto shutoff mechanism and is fully MIL-SPEC. Fitted with an optional 3x, 4x, 5x and 8x lens, this advanced goggle can be easily converted to a long range night vision binocular, and with a full range of additional accessories, the NVS 7 series is among the world’s most versatile night vision devices.

  • NVS 15-3AG

    The NVS 15-3AG auto-gated dual tube night vision goggle has been proven in deployments in conflict zones and by peacekeepers around the world. The model utilizes two advanced Gen 3 image intensifier tubes, with minimum, exportable FOM >1600 and an auto-gated power supply for optimal performace in all light conditions.

    The device has a manual gain control system, built-in IR illuminator, auto shutoff mechanism and is fully MILSPEC. The unit provides users with full depth perception and is ideal for vehicle operation and any other dark environment task requiring acute situational awareness. It also allows for the detachment of the left or right eye device while the proprietary bridge mount provides for interpupillary and other fine adjustments. The NVS 15-3AG can be handheld, head or helmet mounted, while each individual monocular module can be mounted on a variety of weapon systems.

  • NVS 15-3AGBW

    The NVS 15-3AGBW auto-gated dual tube black + white night vision goggle has been proven in deployments in conflict zones and by peacekeepers around the world. The model utilizes two advanced Gen 3 image intensifier tubes, with minimum, exportable FOM >1600 and an auto-gated power supply for optimal performance in all light conditions.

    The device has a manual gain control system, built-in IR illuminator, auto shutoff mechanism and is fully MIL-SPEC. The unit provides users with full depth perception and is ideal for vehicle operation and any other dark environment task requiring acute situational awareness. It also allows for the detachment of the left or right eye device while the proprietary bridge mount provides for interpupillary and other fine adjustments. The NVS 15-3AGBW can be handheld, head or helmet mounted, while each individual monocular module can be mounted on a variety of weapon systems.

  • NVS 15-M

    The NVS 15-M night vision goggles has been proven by deployments in conflict zones and by peacekeepers around the world. NVS 15-M utilize two advanced Gen 3 image intensifier tubes; with minimum, exportable FOM >1600, built-in IR illuminator, and auto shutoff mechanism; and are fully MIL-SPEC.

    The NVS 15-M provides users with full depth perception, and is ideal for vehicle operation and any other dark-environment task requiring acute situational awareness.

  • NVS 15-MAGBW

    The NVS 15-MAGBW auto-gated night vision goggles have been proven by deployments in conflict zones and by peacekeepers around the world. NVS 15-MAGBW utilizes two advanced black and white Gen 3 image intensifier tubes, is fully auto-gated and has a manual gain control system. It also boasts minimum, exportable FOM >1600, built-in IR illuminator, auto shutoff mechanism, and is fully MIL-SPEC.
    The NVS 15-MAGBW provides users with full depth perception, and is ideal for vehicle operation and any other
    dark-environment task requiring acute situational awareness.

  • NVS 18

    TThe NVS 18 QUAD Panoramic Night Vision Goggle, provides users wide field-of-view, helmet-mounted device with either green or white phosphor technology for improved target detection and recognition, 120 FOV allows for quick DIR (Detection, Identification, Reaction) under adverse conditions and is ruggedized for ground applications. The most striking feature of the NVS 18 is the presence of four separate image intensifier tubes with four separate objective lenses arrayed in a panoramic orientation. The center two, giving the operator more depth perception, while two point slightly outward from the center to increase peripheral view. They can also be easily removed and operated as independent handheld viewers. The IPD of the two system can be adjusted on the helmet mount.

NIGHT VISION NOT REQUIRING EXPORT PERMIT

  • NV 66-G2

    The NV 66-G2 night vision goggle provides the ability to observe the terrain under the darkest conditions. This model uses the same approach to night vision as our popular battle-tested NVS 7 series and uses a Generation 2+ image intensifier tube. No export permit is required for this device.

ACCESSORIES

  • NVS 4x Lens

    These high-performance 4x lenses easily mount to the objective lens of Newcon Optik’s NVS goggles. Each add-on lens is either threaded or snapped onto the objective lens of the night vision device. A convenient flip-up objective lens cover, removable rear lens cap and carrying case allow for safe storage and transportation.

  • NVS 5x Lens

    These high performance 5x lenses easily mount to the objective lens of many night vision devices. The lenses can be threaded or snapped onto the objective lenses, depending on the lens magnification. Each unit includes a convenient flip-up objective lens cover, removable rear lens cap and carrying case. Each NVS lens is water resistant.

  • NVS H Mount

    The NVS H Mount is a metal helmet mount for attaching NVS 14 Night Vision Monoculars or NVS 7 Night Vision Goggles to a standard PASGT infantry helmet. The NVS H Mount fits securely onto a PASGT helmet via a rugged strapping device and grooved hooks. While attached to the helmet mount, a night vision device can be positioned directly in front of the operator’s eyes or flipped up. The NVS H Mount is the only mount of its type compatible with NVS 14.

  • NVS S Mount

    NVS S Mount is a ruggedized helmet mount assembly (Rhino Style) providing the user with an easier, more comfortable mounting option when wearing the Night Vision Goggles or Night Vision Monoculars. This mount allows direct attachment of the goggle or monocular to the FAST Helmet or any other compatible Helmet with “VAS Shroud” installed.

  • NVS DS

    Demist Shield to prevent eye-piece fogging: these disposable protective covers screw in to the ocular of Night Vision Devices; they prevent condensation from forming on the optical surfaces during dynamic temperature conditions.

  • NVS SW

    Sacrificial window to protect objective lens of monoculars and goggles.

  • NVS Cam/Video

    Connects monoculars to video and still cameras.

  • NVS U Coupler

    NSN#: 5855-20-011-6791

    NVS U Coupler is a clamp-on mechanical adapter with flip-out feature that provides the ability to attach a night vision monocular (NVS 14 /PVS 14) or goggles (NVS7/ PVS7) to various tactical daytime equipment such as Laser Range Finders, Spotting Scopes, Binoculars, Sniper Scopes, etc.

  • NVS 15 Hard Case

    These MIL-SPEC hard cases can hold any of your NVS 15 night vision systems, along with all their standard accessories, comfortably and securely.

  • NVS 7/ NV 66-G2 Hard Case

    MIL-SPEC hard case for protection while transporting/storing unit and its standard delivery set.
