SPOTTER LRF PRO M

Spotter LRF PRO M – Advanced Tactical Laser Rangefinding System

The Spotter LRF PRO M represents a breakthrough in tactical optics—integrating a high-performance spotting scope and laser rangefinder into a single, mission-ready system. Engineered to MIL-STD-810G standards, it delivers rapid, precise acquisition of range, inclination, and azimuth data for long-distance engagements.

Operational Advantages:

– Faster Target Engagement: Combines ranging and observation into a single streamlined process.
– Enhanced Situational Awareness: Live data sharing with team members and fire control systems.
– Future-Ready Modularity: Supports peripheral devices and software updates for evolving mission requirements.

The Spotter LRF PRO M redefines precision optics for military, law enforcement, and specialized tactical units, delivering unmatched speed, accuracy, and interoperability in the field.

  • Designed for precision and versatility, Spotter LRF PRO M features a 5 km measuring range for long-distance performance.
  • Selectable reticle to adapt viewing options to any environment.
  • 20-60x Variable Magnification: High-resolution, fully multi-coated optics for superior image clarity in all conditions.
  • MIL-Spec Durability: Ruggedized construction for reliable operation in harsh combat environments.
  • Integrated Solution: Etched mil-dot reticle and onboard sensors for real-time data output.
  • Digital Connectivity**: Bluetooth/USB data transfer and LED display for seamless integration with tactical networks.
  • NC Cronus™ App Compatibility: Android™-based control and data sharing via Newcon Optik’s dedicated management software.

Optical

Magnification (x)

20 – 60

Objective lens (mm)

80

Exit pupil diameter (mm)

4 – 1.3

Eye relief (mm)

27

Field of view (°)

2.6 (20x) – 0.9 (60x)

Axial resolution (center), (arcsec)

3.0

Diopters adjustment range, dpt

-5 +4

Device focusing range (m)

12 – ∞

Laser Rangefinder

Eye safety

Class 1, eye safe

Peripheral Compatibility

BT, PC, AndroidTM

Wavelength (nm)

1535

1064 nm laser protection

Optional

Specified Measuring range (m)*

20 – 3000

Measuring range capability (m)

20 – 5,500

Display

Aiming reticle type

Etched reticle (MIL Dot)

Display type

Customized matrix TOLED

Display brightness control

Manual (8 levels)

Mechanical, Electronics and Environmental

Dimensions (mm)

355x106x136

Weight without batteries and accessories (g)

1,950

Operational temperature (°C)

-35 to +55

Storage temperature (°C)

-45 to +65

Waterproof

1m/30min

Environmental conditions

MIL-STD-810G

Tripod mounting pad

Yes

3-axis digital compass

Yes

Internal power supply

2x CR123 Lithium

Battery life (# of measurements)

5,000

Interface

USB, RS232

* 2.3m x 2.3m NATO standard target
